Sheet Metal Auto Stamping Line

Our Sheet Metal Auto Stamping Line delivers precise, stable, and efficient forming for high-volume production. Through automated feeding, stamping,

    The Mission of the Line

Our automatic stamping line enables flat sheet blanks to move through a fully automated sequence of forming operations, gradually shaping, bending, and refining each piece until it becomes a finished, high-precision component.

Modern sheet-metal manufacturing relies on two advanced stamping concepts: Progressive Die Stamping and Transfer Die Stamping. Each solution follows a distinct engineering philosophy and serves different part geometries, production volumes, and automation requirements. Our integrated stamping lines support both approaches, offering a full combination of feeders, robots, transfer units, shuttle carts, and in-line inspection to achieve stable, high-efficiency production.

High flexibility. Complex geometries. Designed for deep-drawn or large components
In a Transfer Die Line, the part is removed from the die at each station and moved to the next forming step by an external transfer mechanism. This allows each station to be completely independent, enabling complex part rotations, multiple drawing stages, and three-dimensional forming processes impossible in progressive dies.

• Transfer mechanisms or NC transfer units: Servo-controlled grippers synchronize with the press to transfer parts with high positional accuracy.
• Shuttle carts / linear transfer platforms: Used for larger panels or multi-press tandem lines.
• 6-axis industrial robots: Ideal for flexible handling, multi-angle placement, part flipping, or integration with vision systems.

• Perfect for deep-drawn, box-type, large, or irregular components
• Greater freedom for forming complexity and part orientation
• Easy to incorporate intermediate inspection or additional operations between stations

• Coil loading & servo feeding system: Ensures smooth, accurate strip advancement to maintain high cyclic speeds.
• Robotic off-loading or part sorting: Industrial robots or picking devices manage finished parts, scrap handling, or transfer to downstream processes.
• In-die sensors: Monitor tool conditions, prevent misfeeds, and protect the tooling during high-speed operation.

• Excellent productivity and cost efficiency for mass production
• Compact structure, minimal handling between operations
• High consistency due to synchronized in-die forming

We deliver fully engineered stamping systems—from tooling design to automation integration—ensuring smooth, synchronized production across multiple forming stages. Whether you require the efficiency of a Progressive Die Line or the flexibility of a Transfer Die Line, our solutions combine:

• Servo presses
• Robotized loading & unloading
• Precision feeding equipment
• Automated transfer systems
• In-line measurement, vision inspection, and quality monitoring
• Complete safety & control systems
